Technical specications
- Standard: IEC60439 IEC61000
- Approval: CE, RoHS, HF test, IK test, ISO9001
- Protection grade: IP66
- Color of base: Gray
- The color of door: Transparent
- Mounting type: Surface
- Material: DB box shell: PC; Zero bar/earth bar: copper
- Fire resistence: 850°C/30s
- Ambient temperature (°C): -5~+40, 50% humidity permitted under max+40°C
- Storage temperature (°C): -40-+75
Overall Dimension
| Model | Overall Dimension | ||
| W | H | D | |
| ZANHC-4 way | 107 | 202 | 100 |
| ZANHC-6 way | 165 | 200 | 100 |
| ZANHC-9 way | 219 | 200 | 100 |
| ZANHC-12 way | 273 | 230 | 110 |
| ZANHC-18 way | 381 | 230 | 115 |
| ZANHC-24 way | 275 | 380 | 115 |
| ZANHC-36 way | 380 | 380 | 116 |
About Us
Why Choose Us
Packaging&Shipping
Our Exhibition
Installation Case
FAQ
Q:How can I check your factory conditions while it’s difficult for me to come to China?
A: We can show you photos and videos of our manufacturing process.
Q:Are you a trading company or a manufacturer?
A:We are a factory that has been established for 12 years.
Q:How long is your delivery time?
A:The delivery date will be determined based on the quantity you require.
Q:Where is your factory located?
A:My factory is located in Liushi Town, Wenzhou City, Yueqing City, Zhejiang Province, China.
Q:If OEM is acceptable?
A:Yes.
